Fitwel Industries LLP is one of the pioneer exporter, manufacturers, and suppliers of Duplex/Super Duplex Steel Forged Fittings in India. We are abided up in providing an extensive range of Duplex Steel UNS S31803 Forged Fittings to our valued customers. This Duplex Steel UNS S32205 Forged Fittings fabricated by using the best quality of raw materials and urbane technology by our proficient experts. We offer A1 quality of high-quality Duplex Steel Forged Fittings, which shows great weakness quality and in addition remarkable imperviousness to stretch consumption breaking, cleft, setting, disintegration, and general corrosion in extreme situations. In Duplex Steel Forged Threaded Fittings, corrosion resistance contingent typically on the composition of the alloy, where for crevice corrosion resistance and chloride pitting, their chromium, nitrogen, and molybdenum content are most significant. Duplex Steel Forged Socket Weld Fittings have a range of corrosion resistance, similar to the range for austenitic stainless steels, which is from Type 304 or 316 to six percent of molybdenum stainless steels. Duplex Steel Forged Threaded Elbow Fittings does not readily corrode, rust or stain with water as ordinary steel does. However, Duplex Steel Forged Socket Weld Elbow Fittings is not fully stain-proof in low-oxygen, high-salinity, or poor air-circulation environments. We have a long process of quality control, which helps us evaluate the durability and reliability of our products under different parameters. We do test and confirm the finish and the dimensional accuracy of all Duplex Steel UNS S31803 Forged Pipe Elbow. We make sure all our products are sufficiently fit to provide maximum usability. We have delivered these Duplex Steel UNS S31803/ S32205 Forged Union in a variety of industries that include Oil & Gas Exploration, Pulp & Paper Digesters, and Chlorine processing.
We have strategized our services to provide maximum benefits to our customers, such as on-time delivery. We have gained a huge customer base in India and Abroad through our quality products, as well as services. We have a highly equipped infrastructure facility that allows us to provide world-class products. Duplex Steel Forged Threaded Tee Fittings differs from carbon steel by the amount of chromium present. There are various grades and surface finishes of Duplex Steel Forged Socket Weld Tee Fittings to suit the environment the alloy must endure. In addition, the high nickel content of Duplex Steel Forged Threaded Coupling Fittings leads to price volatility which is unwelcome to many end-users. Besides, Duplex Steel Forged Socket Weld Coupling Fittings also exhibits an irregular pattern and behavior while undergoing several hot working processes (especially hot working processes). We also offer these fittings at the best prices to our customers. Also We offer wide range of Duplex Steel ASTM A182 Forged Fittings such as Duplex Steel 2205 Forged Elbow, Duplex S31803 Equal Tee, Duplex Steel S32205 Coupling, 2205 Duplex Steel Pipe Cap, Duplex Steel S32205 Union, Duplex Steel 2205 Bushing, Duplex Steel 2205 Plug, S31803 Duplex Steel Pipe Nipple, Duplex Steel S32205 Street Elbow.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Threaded and Socket Weld Pipe Fittings
Products | Size | |
ASTM A182 Duplex Steel 90° Elbows | ASTM A182 Duplex Steel 45° Elbows | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
ASTM A182 Duplex Steel Forged Caps | ASTM A182 Duplex Steel Couplings | |
ASTM A182 Duplex Steel Forged Tees | ASTM A182 Duplex Steel Unions | |
ASTM A182 Duplex Steel Forged Cross | ASTM A182 Duplex Steel Inserts | |
ASTM A182 Duplex Steel Forged Plug | ASTM A182 Duplex Steel Street Elbows | |
ASTM A182 Duplex Steel Bushings | ASTM A182 Duplex Steel Pipe Nipple |
Duplex Steel Forged Fittings Manufacturing Standards :
ASTM A182 - ASME SA182 | Standard Specification for Wrought Austenitic Duplex Steel Piping Fittings |
ASME B16.11 | Socket Welding and Threaded Forged Fittings |
MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
MSS SP-95 | Swage(d) Nipples and Bull Plugs |
BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
STANDARD | WERKSTOFF NR. | UNS |
Duplex 2205 | 1.4462 | S31803 / S32205 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 - 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
S31803 / S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
Duplex Steel Forged Pipe Fittings | Duplex Steel High Pressure Forged Fittings |
Duplex Steel 2205 Socket Weld Fittings | Duplex Steel S31803 Threaded Fittings |
Duplex Steel UNS S32205 Socket Weld 90 Deg Elbow | Duplex Steel F51 Threaded 90 Deg Elbow |
Duplex Steel Socket Weld 45 Degree Elbow Suppliers | ANSI 2205 Duplex Steel Screwed 45 Degree Elbow |
Duplex Steel Gr. F52 Forged Tee Dealer | Duplex Steel F53 Threaded Tee Exporter |
Duplex Steel S31803 Socket Weld Cross Stockholder | UNS S32205 Threaded / Screwed Cross Distributors |
Duplex Steel UNS S31803 Socket Weld Half Coupling | Duplex Steel Threaded Half Coupling Manufacturer |
Duplex Steel DIN 1.4462 Full Coupling | Duplex Steel 2205 Coupling |
Duplex Steel Socket Weld Cap | Ferritic / Austenitic Duplex Steel Screwed Cap |
ANSI B16.11 Duplex Steel Socket Weld Union | Duplex Steel 2205 Threaded / Screwed Union Stockist |
ASTM A182 Duplex Steel 2205 Screwed Hex Plug | ASME SA182 Duplex Steel Square Plug |
Duplex Steel F55 Reducing Tee | Duplex Steel 2205 Threaded / Screwed Bushing |
A182 Duplex Steel F57 Hex Nipples | ASME SA182M Duplex Steel Swage Nipple |
2205 Duplex Threaded Street Elbow | Duplex Steel Threaded / Screwed Pipe Nipple |
Duplex Steel F60 Socket weld Unequal Tee | Duplex Steel ASME B16.11 Threaded Unequal Tee |
ASTM A182 Duplex Forged Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A182 Duplex Steel Forged Pipe Fittings through a worldwide network of stock-keeping branches. These ASTM A182 Duplex Steel Forged Fittings is use in various industries like :
