Super Duplex Steel End Cap Manufacturer in India

Request a Call Back


Super Duplex Steel UNS s32760 End Cap Manufacturer in Mumbai, India

ASME B16.9 Buttweld End Cap

Fitwel Industries LLP is one of the top leading manufacturer of Duplex Steel Pipe Cap in India. Super Duplex Steel Pipe End Cap has excellent resistance to chloride-ion stress-corrosion cracking, and as well shows appropriate resistance to a number of oxidizing environments. ASME B16.9 Cap is very much resistant to chemical corrosion and oxidation and has some high stress-rupture effectiveness and low creep rates under high stresses at temperatures after suitable heat treatment. Our ASME B16.9 End Cap is accessible to our valuable customers in a different range of diameters, wall thicknesses, and sizes in customized form and also at quite affordable rates. Meanwhile, we offer different types of these fitting such as Duplex Steel ASME B16.9 Buttweld Pipe Cap And Super Duplex Steel ASME B16.9 Buttweld Pipe Cap.
Duplex Steel Pipe End Cap in India, usually liquid or gas-tight, covers the otherwise open end of a pipe. A DIN 2617 Cap attaches to the exterior of a pipe and may have a solvent weld socket end or a female-threaded interior. The exterior of an industrial cap may be round, square, rectangular, U- or I-shaped, or may have a handgrip. If a solvent-weld cap is used to provide for a future connection point, several inches of pipe must be left before the cap; when the cap is cut off for the future connection, enough pipe must remain to allow a new fitting to be glued onto it.

What is Super Duplex Steel Pipe End Caps?

Super Duplex Steel Pipe End Caps or stop ends are commonly used in pipe work to dead end the flow of gas or water. We stock a variety of different types, which are connected slightly differently to one another. Depending on the existing pipe work, you can choose from either brass, copper or plastic in a range if different diameters.


ASME B16.9 Duplex/Super Duplex Steel Pipe End Caps NPS 1/2 - 48 Dimension

Duplex/Super Duplex Steel Pipe End Cap
NPS O.D.
D
LENGTH
H
LENGTH
H1
1/2 21.3 25 25
3/4 26.7 25 25
1 33.4 38 38
42.2 38 38
48.3 38 38
2 60.3 38 44
73 38 51
3 88.9 51 64
101.6 64 76
4 114.3 64 76
5 141.3 76 89
6 168.3 89 102
8 219.1 102 127
10 273 127 152
12 323.8 152 178
14 355.6 165 191
16 406.4 178 203

ASME B16.9 Duplex/Super Duplex Steel Pipe End Caps Dimension Tolerances

Nominal Pipe Size 1/2 to 2½ 3 to 3½ 4 5 to 8
Outside Diameter
at Bevel (D)
+ 1.6
- 0.8
1.6 1.6 + 2.4
- 1.6
Inside Diameter at End 0.8 1.6 1.6 1.6
Overall Length (H) 3 3 3 6
Nominal Pipe Size 10 to 18 20 to 24 26 to 30 32 to 48
Outside Diameter
at Bevel (D)
+ 4
- 3.2
+ 6.4
- 4.8
+ 6.4
- 4.8
+ 6.4
- 4.8
Inside Diameter at End 3.2 4.8 + 6.4
- 4.8
+ 6.4
- 4.8
Overall Length (H) 6 6 10 10
Wall Thickness (t) Not less than 87.5% of Nominal Wall Thickness

Dimensional tolerances are in millimeters unless otherwise indicated and are equal & except as noted.


Standard Specification For Duplex/Super Duplex Steel Buttweld End Cap


Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

Size : 1/2" (15 NB) to 48" (1200NB)

Type : Seamless / ERW / Welded / Fabricated

Thickness : Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.

Form : End Caps, Pipe Caps, Duplex/Super Duplex Steel Pipe End Caps.


Material & Grades of Duplex/Super Duplex Steel Buttweld End Cap :

Duplex & Super Duplex Steel Buttweld End Cap :
ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werkstoff No. 1.4462


ASME B16.9 Duplex/Super Duplex Steel Buttweld End Cap Available Types

Buttweld End Cap Butt Weld Pipe Caps
ASME B16.9 Butt weld End Cap Steel Cap Pipe Fittings
Duplex/Super Duplex Steel End Cap Suppliers SS Buttweld End Caps Fitting
ANSI B16.9 Buttweld End Cap Dealer ASME B16.28 Buttweld Pipe Cap Exporter
Welded Butt weld End Caps Stockholder Seamless Butt weld End Cap Distributors


Call-09987994248. Find here online the top ISO certified manufacturers, exporter & suppliers of UNS s32760 Super duplex end cap, UNS s32250 Super duplex end cap, UNS s31803 Duplex Steel end cap, UNS s32205 Duplex Steel end cap, Super duplex stainless steel end cap, duplex stainless steel end cap in Mumbai, Chennai, Pune, Delhi, India.

Other Names: Duplex/Super Duplex Steel Pipe End Cap, Buttweld End cap, Duplex/Super Duplex Steel Pipe End Cap Fittings

Material: Duplex/Super Duplex Steel

Brand: Fitwel Industries LLP

Manufacturer: Fitwel Industries LLP

Suppliers & Exporter: Fitwel Industries LLP

Rating: 4.7/5 based on 423 customer reviews

Duplex/Super Duplex Steel Pipe End Cap Application

ASME B16.9 buttweld Duplex/Super Duplex Steel Pipe End Cap are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of buttweld Duplex/Super Duplex Steel Pipe End Cap through a worldwide network of stock-keeping branches. These buttweld elbows is used in various industries like:

  • Duplex/Super Duplex Steel Pipe End Cap For Oil & Gas Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Petrochemical Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Engineering Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Chemical Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Sugar Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Power Generation Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Fertilizers Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Food Processing Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Polymer Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Dairy Industries
  • Duplex/Super Duplex Steel Pipe End Cap For Bio-Pharma Industries


  • Coutries & Cities We Serve


    We are renowned & most acclaimed Manufacturer, Suppliers & Exporter And Stockist of Buttweld Pipe End Cap of Duplex/Super Duplex Steel Material.

    For More Information About Duplex/Super Duplex Steel Buttweld End Cap Please Call 91-22-2382 9256 or Send an Email to sales@fitwelindia.com
