Stainless Steel 316Ti Buttweld Fittings

Request a Call Back


Stainless Steel 316Ti Buttweld Pipe Fittings Manufacturers & Exporter in India

ASME B16.9 Buttweld Equal Tee

Fitwel Industries LLP is a known manufacturer of SS 316Ti Pipe Fittings, which shows itself as a tight band of serious consumption neighboring a weld. Our Stainless Steel 316Ti Butt Weld Fittings can be cold moved to accomplish the temper properties needed by explicit clients as well as assembling prerequisites. These Stainless Steel 316Ti Butt Weld Pipe Fittings have comparable erosion protection from sharpening as the low carbon variant 316L. The weldability of our Stainless Steel 316Ti Tee Pipe Fittings can be thought to be comparative. Neither of the evaluations can be required to weld 'simpler' or 'better' than-the-other. The titanium particles settle the design of these Stainless Steel 316Ti Elbow Pipe Fittings at temperatures more than 800 Degree C, where this forestalls carbide precipitation at the grain limits and shields the metal from erosion. Cold working of our Stainless Steel 316Ti Bend Pipe Fittings will increment both strength and hardness of hardened steel 316.

ASTM A403 WP316Ti Stainless Steel 316Ti Buttweld Fittings, Werkstoff No 1.4571, SS WP316Ti, SS UNS S31600, ANSI B16.9, ANSI B16.28, MSS SP-43-79, Buttweld Fittings, SS 316Ti Pipe Fittings, ASME B16.9 Steel 316Ti Cross Manufacturers, 316Ti SS Long Radius Bends, 316Ti SS End Pipe Cap Exporter, 316Ti Stainless Steel Bend Exporter in Saudi Arabia, SS 316Ti Stubends Stock Holder. Stainless Steel 316Ti Pipe Fittings.

There may be a few situations where equipment can see both elevated temperature service and occasional aqueous corrosion issues where a stabilized grade like these Stainless Steel 316Ti Reducer Pipe Fittings are warranted. Our Stainless Steel 316Ti Cross Pipe Fittings are often used for Chemical processing, Springs, Fasteners, Thread inserts, Wire mesh, and so on. Special consideration is required to avoid weld “hot cracking” in these Stainless Steel 316Ti Stub End Pipe Fittings by assuring the formation of ferrite in the weld deposit. Consequently, the Titanium is responsible for curbing Chromium-carbide precipitation and the corrosion due to it. Our UNS S3135 SS Pipe Elbows are equipped for rigid applications at low and high temperatures, manufactured in standard as well as custom-made bends that service the petroleum and pulp industry. Another advantage of the Titanium content is that it counters Intercrystalline Corrosion (ICC) during high heat processes thus retaining the original structure of the steel. We have effeciently supplied our export quality DIN 1.4571 Seamless Buttweld Fittings to the brewery and mining industry. Also We offer wide range of Stainless Steel ASTM A403 WP316Ti Pipe Fittings such as SS WP316Ti tee, WP316Ti SS End Pipe Cap, SS 316Ti reducer, SS 316Ti cross, SS 316Ti elbow, SS 316Ti stub ends etc.

Standard Specification For Stainless Steel ASTM A403 WP316Ti Pipe Fittings


Specifications : ASTM A403 / ASME SA403

Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type : Seamless / Welded / Fabricated

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS



Call@ +91 9987994248. Find here online the best quality ASTM A403 WP316Ti Stainless Steel 316Ti Pipe Fittings, SS 316Ti Buttweld Fittings, SS 316Ti Pipe Fittings, UNS S30403 Stainless Steel 316Ti Buttweld Fittings contains low carbon & having good strength the leading manufacturers, exporter & suppliers in Mumbai, Ahmedabad, Pune, Chennai, India.

Other Names: ASTM A403 WP316Ti Stainless Steel 316Ti Buttweld Fittings, Werkstoff No 1.4571, SS WP316Ti, SS UNS S31600, ANSI B16.9, ANSI B16.28, MSS SP-43-79, Buttweld Fittings, SS 316Ti Pipe Fittings.

Material: Stainless Steel Grade 316Ti

Brand: Fitwel Industries LLP

Manufacturer: Fitwel Industries LLP

Suppliers & Exporter: Fitwel Industries LLP

Rating: 4.7/5 based on 67 customer reviews


ASTM A403 WP316Ti Stainless Steel Pipe Fittings

Seamless/ Welded 100% Radiography Tested

Products Size
ASTM A403 WP316Ti SS Elbow – Long Radius ASTM A403 WP316Ti SS Stub Ends Sizes 1/2″ – 48″
ASTM A403 WP316Ti SS Elbow – Short Radius ASTM A403 WP316Ti SS Cross
ASTM A403 WP316Ti SS Reducing Elbow ASTM A403 WP316Ti SS Reducing Cross
ASTM A403 WP316Ti SS 45° Elbow ASTM A403 WP316Ti SS Tees
ASTM A403 WP316Ti SS Fabricated Tee ASTM A403 WP316Ti SS End Cap
ASTM A403 WP316Ti SS Reducer ASTM A403 WP316Ti SS Coupling
ASTM A403 WP316Ti SS Concentric Reducer ASTM A403 WP316Ti SS Pipe Nipple
ASTM A403 WP316Ti SS Eccentric Reducer ASTM A403 WP316Ti SS 5D Elbow
ASTM A403 WP316Ti SS 3D Elbow ASTM A403 WP316Ti SS Welded Pipe Fittings

ASME SA403 316Ti Stainless Steel Buttweld Fittings Equivalent Grades
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 316Ti 1.4571 S31635 SUS 316Ti 320S31 08Ch17N13M2T Z6CNDT17‐123 X6CrNiMoTi17-12-2

Types Of Grade 316Ti Stainless Steel Buttweld Pipe Fittings

Chemical Composition of Grade WP316Ti Stainless Steel Butt weld Fittings
Grade C Mn Si P S Cr Mo Ni Fe
SS 316Ti 0.08 max 2.0 max 0.75 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.395 min

Mechanical Properties of ASTM A403 SS 316Ti Butt weld Pipe Fittings
Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1399 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

ASTM A403 WP316Ti Stainless Steel Buttweld Fittings Available Types
Stainless Steel 316Ti Pipe Fittings Stainless Steel 316Ti Buttweld Pipe Fittings
Stainless Steel 316Ti Seamless Pipe Fittings Stainless Steel 316Ti Welded Pipe Fittings
Stainless Steel UNS S31635 Pipe Elbow Stainless Steel 316Ti Buttweld Tee
SS 316Ti Buttweld Reducer Suppliers ANSI 316Ti Stainless Steel Pipe Fittings
SS 316Ti Stubends Dealer SS 316Ti Pipe Fittings Exporter
SS 316Ti Butt weld Fittings Stockholder Steel 316Ti Pipe End Cap Distributors
Stainless Steel SUS 316Ti 45deg.Elbow SS 316Ti 90deg. LR Elbow Manufacturer
Stainless Steel DIN 1.4571 Pipe Tee Stainless Steel BS 320S31 Cross
Stainless Steel 316Ti Buttweld Reducing Nipple Stainless Steel 316Ti Short Radius Elbow
ANSI B16.9 SS 316Ti Buttweld Fitting SS 316Ti End Pipe Cap Stockist
ASTM A403 SS WP316Ti Welded Pipe Fittings ASME SA403 SS 316Ti Pipe Fittings

Stainless Steel 316Ti Buttweld Pipe Fittings Application

ASTM A403 WP316Ti Pipe Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A403 WP316Ti Stainless Steel Buttweld Pipe Fittings through a worldwide network of stock-keeping branches. These ASTM A403 WP316Ti Buttweld Fittings is use in various industries like :

  • Stainless Steel WP316Ti Buttweld Pipe Fitting uses in Oil and Gas Pipeline
  • ASTM A403 SS WP316Ti Buttweld Pipe Fittings uses in Chemical Industry
  • Grade 316Ti Stainless Steel Pipe Fittings uses in Plumbing
  • Stainless Steel ASTM A403 WP316Ti Buttweld Pipe Fittings uses in Heating
  • ASTM A403 WP316Ti Pipe Fittings uses in Water Supply Systems
  • ASTM A403 WP316Ti Stainless Steel Buttweld Fittings uses in Power Plant
  • SS 316Ti Butt weld Pipe Fittings uses in Paper & Pulp Industry
  • 316Ti SS Buttweld Pipe Fittings uses in General Purpose Applications
  • ASME SA403 Stainless Steel WP316Ti Pipe Fittings uses in Fabrication Industry
  • Stainless Steel 316Ti Buttweld Fittings uses in Food Processing Industry
  • SS WP316Ti Buttweld Pipe Fittings uses in Structural Pipe
