Titanium Grade 2/Grade 5 Forged Fittings Manufacturers, Suppliers & Exporter in India

ASME B16.9 Buttweld Equal Tee

Fitwel Industries LLP is one of the top leading manufacturers, suppliers & exporter of offering Titanium Forged Fittings, Titanium Socket Weld Fittings, Titanium Threaded Fittings in India & abroad. We are engaged in offering high-quality Titanium Forged Fittings which have some best attributes of prominent engineering applications. We are stocking high quality forged fittings in different designations, standards, specifications, dimensions to fulfill the urgent requirement of the clients. To provide continuous service we are producing titanium forged fittings with respect to set industrial norms. These fittings are provided in different shapes such as reducer, elbow, tee, cross, stub bends, and other customized shapes. The titanium grade is combined with high corrosion resistance, weldability, and good strength. The compositions of resistive elements make it worthwhile for reducing the environment. Moreover, these are withstood at elevated temperatures without any deformations. Forged fittings are processed from high-quality raw materials using the latest machines and technologies. Importantly, these are treated with a hot and cold working process that enhances their workability. These forged fittings are coated with satin coat and bright black polish this prevents rusting.

Titanium Forged Fittings, Titanium Alloy Forged Pipe Fittings, Titanium Gr 2 / Gr 5 Threaded Fittings, Titanium Grade 2 Socket weld Fittings, Titanium Grade 5 Forged Pipe Caps, UNS R50400 Forged Adapter Supplier, DIN 3.7165 Titanium threaded Union, Ti Gr2 Forged Tees Dealers in India, Titanium Alloy Socket Weld Cross, 45degree Titanium GR5 Elbow in UAE, Titanium Bull Plug Distributor, Titanium Gr 2/5 Boss in Qatar, Ti Grade2 90degree Elbow in Saudi Arabia, Titanium Gr5 Forged Hex Head Bushing Manufaturer, UNS N56400 Hex Nipple Fittings Exporter, DIN 3.7035 Forged Coupling Exporter, Titanium Gr 2/Gr 5 Swage Nipple, Titanium Gr 5 Street Elbow, Titanium Alloy Plug, Titanium Gr 2 Pipe Nipple Stockist, ANSI Titanium Gr2/5 Reducing Coupling Suppliers

Fitwel Industries LLP offers high-quality Titanium Forged Threaded Fittings, which has some best features to offer such as highly efficient, rust-proof, longer service life, and more. Continuous service temperatures in these Titanium Forged Threaded Elbow can reach up to 800 Degree F with occasional, intermittent service at 1000 Degree F. Its high strength, low weight ratio gives our Titanium Forged Threaded Tee a diversified range of applications ranging from medical applications to aerospace and automotive fabrication. These Titanium Forged Threaded Cross combines excellent corrosion resistance and weldability with good strength, ductility, and formability. Meanwhile, our Titanium Forged Threaded Cap is also being offered in different sizes and shapes to our customers. We also offer these Titanium Forged Threaded Fittings at market leading prices to our clients. Our Titanium Forged Threaded Coupling is highly resistant to corrosion and has excellent physical and mechanical properties. These Titanium Forged Threaded Union can be welded by the conventional techniques used with austenitic stainless steels. Nevertheless, the heat-affected zone in our Titanium Forged Threaded Bushing must be protected by either argon, helium, or a mixture because of the material’s reactivity. In general, if higher the purity of these Titanium Forged Threaded Plug’s greater the corrosion resistance. Our UNS R50250 Titanium Screwed/Threaded Forged Fittings are widely used in aircraft manufacturing components as they are highly ductile yet as strong as nails.


Standard Specification For Titanium ASTM B381 Forged Pipe Fittings


Specifications : ASTM B381 / ASME SB381

Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799

Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)

Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Type : Socketweld Fittings, Screwed-Threaded Fittings

Grades : Titanium Gr. 1, Titanium Gr. 2, Titanium Gr. 4, Titanium Gr. 5, Titanium Gr. 7



Call@ 9987994248. Find here online top-quality Titanium gr 5 Forged Fittings, Titanium gr 2 Forged Fittings, Titanium gr 5 Threaded fittings/Socket weld fittings, Titanium gr 2 Threaded fittings/Socket weld fittings. Titanium Forged Fittings, Titanium Threaded Fittings manufacturers & suppliers in Mumbai, Ahmedabad, Chennai, India.

Other Names: Titanium Grade 2/Grade 5

Material: Titanium Grade 2/Grade 5

Brand: Fitwel Industries LLP

Manufacturer: Fitwel Industries LLP

Suppliers & Exporter: Fitwel Industries LLP

Rating: 4.4/5 based on 57 customer reviews


ASTM B381 Titanium Forged Fittings

Threaded and Socket Weld Pipe Fittings

Products Size
Titanium 90° Elbows Titanium 45° Elbows Sizes 1/8″– 4″
Pressure Ratings –
2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Titanium Forged Caps Titanium Couplings
Titanium Forged Tees Titanium Unions
Titanium Forged Cross Titanium Inserts
Titanium Forged Plug Titanium Street Elbows
Titanium Bushings Titanium Pipe Nipple

Types Of Special Alloy Forged Fittings


Titanium Forged Fittings Standards / Types And Pressure Class :

ASTM B381 - ASME SB381 Standard Specification for Titanium Piping Fittings
ASME B16.11 Socket Welding and Threaded Forged Fittings
MSS SP-43 Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
MSS SP-95 Swage(d) Nipples and Bull Plugs
BS3799 Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry

ASME SB564 Titanium Forged Fittings Equivalent Grades

STANDARD WERKSTOFF NR. UNS
Titanium Gr. 2 3.7035 R50400
Titanium Gr. 5 3.7165 N56400

Chemical Composition of Titanium High Pressure Fittings

Grade Ti C Fe H N O Al V
Ti Grade2 99.2 min 0.1 max 0.3 max 0.015 max 0.03 max 0.25 max - -
Ti Grade5 90 min - 0.25 max - - 0.2 max 6 min 4 min

Mechanical Properties of ASTM B564 Titanium Forged Pipe Fittings

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Titanium Gr. 2 4.5 g/cm3 1665 °C (3030 °F) Psi – 49900 , MPa – 344 Psi – 39900 , MPa – 275 20 %
Titanium Gr. 5 4.43 g/cm3 1632 °C (2970 °F) Psi – 138000 , MPa – 950 Psi – 128000 , MPa – 880 14 %

ASTM B564 Titanium Forged Fittings Available Types

Titanium Forged Pipe Fittings Titanium High Pressure Forged Fittings
Titanium Socket Weld Fittings Titanium Gr.2 Threaded Fittings
Titanium UNS R50400 Socket Weld 90 Deg Elbow Titanium Threaded 90 Deg Elbow
Titanium Gr. 5 Socket Weld 45 Degree Elbow Suppliers ANSI Titanium Screwed 45 Degree Elbow
Titanium Gr. 5 Forged Tee Dealer Titanium Grade 4 Threaded Tee Exporter
Titanium DIN 3.7035 Socket Weld Cross Stockholder Titanium Gr. 5 Threaded / Screwed Cross Distributors
Titanium UNS N56400 Socket Weld Half Coupling Titanium Threaded Half Coupling Manufacturer
Titanium Gr. 5 Full Coupling Titanium DIN 3.7165 Coupling
Titanium Grade 4 Socket Weld Cap Gr. 5 Titanium Screwed Cap
ANSI B16.11 Titanium Gr. 5 Socket Weld Union Titanium Threaded / Screwed Union Stockist
ASTM B381 Titanium Screwed Hex Plug ASME SB381 Titanium Gr. 5 Square Plug
Titanium Gr. 5 Reducing Tee Titanium Gr. 2 Threaded / Screwed Bushing
B381 Titanium Hex Nipples ASME SB381M Titanium Gr. 2 Swage Nipple
Titanium Gr. 7 Threaded Street Elbow Titanium Threaded / Screwed Pipe Nipple
Titanium Gr. 5 Socket weld Unequal Tee Titanium ASME B16.11 Threaded Unequal Tee

Titanium Socket weld / Threaded Forged Fittings Application

ASTM B381 Titanium Forged Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM B381 Titanium Forged Pipe Fittings through a worldwide network of stock-keeping branches. These ASTM B381 Forged Fittings is use in various industries like :

  • Titanium Forged Fittings uses in Oil and Gas Pipeline
  • ASTM B381 Titanium Socket weld Fittings uses in Chemical Industry
  • Titanium Gr. 2 Forged Fittings uses in Plumbing
  • Titanium Gr. 5 Threaded Fittings uses in Heating
  • ASTM B381 Titanium Forged Fittings uses in Water Supply Systems
  • ASTM B381 Titanium Forged High Pressure Fittings uses in Power Plant
  • Titanium Forged Fittings uses in Paper & Pulp Industry
  • Titanium Forged Pipe Fittings uses in General Purpose Applications
  • ASME SB381 Titanium Forged Fittings uses in Fabrication Industry
  • Titanium Gr. 5 Forged Fittings uses in Food Processing Industry
  • Titanium High Pressure Fittings uses in Structural Pipe
