Fitwel Industries LLP is a leading manufacturer, exporter, and supplier of Stainless Steel 310s Forged Fittings, Stainless Steel 310s Threaded Fittings, Stainless Steel 310s Socket Weld Fittings. It is an organization that has received ISO certification and one that gives a definitive advantage to its clients. Sensible costs and excellent raw materials are ensured to the customer base. This grade of Stainless Steel is an austenitic combination that shows a significant component of warmth obstruction. Stainless Steel 310 Forged Pipe Elbows are made with extraordinary weldability, toughness, and protection from oxidation in outrageous temperatures.
Fitwel Industries LLP has instilled the utilization of cutting edge innovation and very good quality modern apparatus for the production of Stainless Steel 310 Socketweld Fittings. This specific fitting is intended to permit simple and quick disengagement of lines with the end goal of upkeep or installation substitution. Stainless Steel 310s Forged Tee has a powerful plan and exact measurements. It is against destructive and simple to introduce. Stainless Steel 310s Forged Fittings are made accessible in various shapes and sizes to customers according to their particular requirements. Fitwel Industries LLP is an established supplier of a vast range of the above-mentioned fittings under multiple grades. Also We offer wide range of Stainless Steel ASTM A182 310 Forged Fittings such as SS 310 Forged Elbow, SS 310S Equal Tee, SS 310 Coupling, SS 310 Pipe Cap, SS 310H Union, SS 310 Bushing, SS 310 Plug, SS 310S Pipe Nipple, SS 310H Street Elbow.
We mainly produce two methods of fittings for our products, one SS 310 Forged Socket Weld Fittings where the part to be fitted goes into a recessed area of the other part which can be a pipe or a fitting. The other, SS 310 Forged Threaded Fittings come with different thread sizes for both male and females and accommodates the fitting of most of the standard products already produced in the market. SS 310 Forged Tees is a short length of a pipe with a lateral connection at a right angle to the pipeline. It is mostly used to connect many pipelines to a single pipe through two outlets. Typically, they contain one inlet. SS 310 Forged Cross on the other hand has one inlet and three outlets or the other way round, to effectively divide or combine the flow. The SS 310 Forged Coupling is another connector between two pipes which is a socket at one end or both the ends that effectively join the pipes together. SS 310 Forged Union is used to effectively provide a means of easy connection and disconnection, even many times if needed. A typical SS 310 Forged Nipple contains male threads on either end to join two pipes or fittings together. Lastly, the SS 310 Forged Elbow is one of our prime productions due to its high reliability and the flexibility we offer to fabricate any bend in the elbow required as per the customer. The typical bends available are 90 and 45.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Threaded and Socket Weld Pipe Fittings
Products | Size | |
ASTM A182 SS 310 90° Elbows | ASTM A182 SS 310 45° Elbows | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
ASTM A182 SS 310S Forged Caps | ASTM A182 SS 310 Couplings | |
ASTM A182 SS 310 Forged Tees | ASTM A182 SS 310H Unions | |
ASTM A182 SS 310H Forged Cross | ASTM A182 SS 310 Inserts | |
ASTM A182 SS 310 Forged Plug | ASTM A182 SS 310S Street Elbows | |
ASTM A182 SS 310S Bushings | ASTM A182 SS 310 Pipe Nipple |
SS 310 / 310S / 310H Forged Fittings Manufacturing Standards :
ASTM A182 - ASME SA182 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
ASME B16.11 | Socket Welding and Threaded Forged Fittings |
MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
MSS SP-95 | Swage(d) Nipples and Bull Plugs |
BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | - | X15CrNi25-20 |
SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | - | X8CrNi25-21 |
SS 310H | - | S31009 | - | - | - | - | - |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 - 26.00 | 0.10 max | 19.00 - 21.00 | 54.7 min |
SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 - 26.00 | 0.75 max | 19.00 - 21.00 | 53.095 min |
SS 310H | 0.04 – 0.10 | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 - 26.00 | - | 19.00 - 21.00 | 53.885 min |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
Stainless Steel 310 Forged Pipe Fittings | Stainless Steel 310S High Pressure Forged Fittings |
Stainless Steel 310H Socket Weld Fittings | Stainless Steel 310 Threaded Fittings |
Stainless Steel UNS S31000 Socket Weld 90 Deg Elbow | Stainless Steel 310 Threaded 90 Deg Elbow |
SS 310 Socket Weld 45 Degree Elbow Suppliers | ANSI 310H Stainless Steel Screwed 45 Degree Elbow |
SS 310S Forged Tee Dealer | SS 310 Threaded Tee Exporter |
SS 310 Socket Weld Cross Stockholder | Steel 310S Threaded / Screwed Cross Distributors |
Stainless Steel SUS 310H Socket Weld Half Coupling | SS 310 Threaded Half Coupling Manufacturer |
Stainless Steel DIN 1.4841 Full Coupling | Stainless Steel A182 310H Coupling |
Stainless Steel 310S Socket Weld Cap | Stainless 310 Screwed Cap |
ANSI B16.11 SS 310 Socket Weld Union | SS 310H Threaded / Screwed Union Stockist |
ASTM A182 SS 310 Screwed Hex Plug | ASME SA182 SS 310 Square Plug |
Stainless Steel DIN 1.4845 Reducing Tee | 310 SS Threaded / Screwed Bushing |
A182 SS 310 Hex Nipples | ASME SA182M SS 310 Swage Nipple |
Steel UNS S31008 Threaded Street Elbow | SS 310 Threaded / Screwed Pipe Nipple |
Stainless Steel UNS S31009 Socket weld Unequal Tee | SS 310 ASME B16.11 Threaded Unequal Tee |
ASTM A182 310 / 310S / 310H Forged Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A182 310 / 310S / 310H Stainless Steel Forged Pipe Fittings through a worldwide network of stock-keeping branches. These ASTM A182 310 / 310S / 310H Forged Fittings is use in various industries like :
