Stainless Steel 304L Flanges

Request a Call Back


Stainless Steel 304L Flanges Manufacturers, Suppliers & Exporter in India

ASME B16.9 Buttweld Equal Tee

Fitwel Industries LLP excels in the craft of creating products that are upgraded consistently to accommodate new trends, services that consider every customer and his unique requisites, and deliver a complete package that fulfills the undertaken order as well as satisfies the customer. SS A182 304 Flanges has excellent forming as well as welding properties. The balanced austenitic microstructure of 304 stainless steel flanges enables it to be severely deep drawn without the need for intermediate annealing. This means that this stainless steel grade is dominant in the manufacture of drawn stainless parts in kitchen types of equipment such as sinks, hollow-ware, and saucepans. The low carbon chemistry of SS A182 304l Flanges works in combination with the added nitrogen, enabling the alloy grade 304L to meet the mechanical properties of its predecessor 304. SS A182 304l Flanges material chemically contains chromium and nickel in an 18-8 ratio. Stainless Steel 304l flanges offer good resistance to atmospheric corrosion, as well as, both mildly oxidizing and reductive environments. The ASTM a182 f304l flange has excellent resistance to intergranular corrosion in an as-welded condition. Another important property of the werkstoff a182 f304l is its excellent strength and toughness. These two mechanical properties aid the flanges in performing well even at cryogenic temperature environments. Stainless steel grade 304L exhibits non-magnetic behavior in the annealed condition, although the alloy can become slightly magnetic as a result of cold working or welding. SA 182 f304l material can be easily welded and processed by conventional shop fabrication techniques.

Stainless Steel 304L Flanges, DIN 1.4306/1.4307 Flanges, ASTM A182 SS 304L Weld neck Flanges (WNRF), SS 304L Weld Neck Flanges, SS 304L Socket Weld Flanges, SS 304L Ring Type Joint Flanges, UNS S30403 Blind Flanges, SS 304L Nipo Flange, SS 304L Orifice Flanges, Stainless Steel 304L Flanges, ss 304L Flange, ss 304L fittings flange, ASTM A182 304L Flange, Werkstoff No 1.4307, SS UNS S30403, ASME 16.11, MSS SP-79, 83, 95, 97, 304L fitting flanges.

The high chromium content of the a182-f304l material provides the alloy with good resistance when exposed to oxidizing solutions such as nitric acid up to 55% of its weight as well as in high-temperature conditions up to 176°F. The SS A182 f304l flange is also known for its resistance to moderately aggressive organic acids such as acetic acid. The nickel present in the alloy of a182 f304l provides resistance in a moderately reductive solution containing environments. The resistance against reductive compounds or solutions includes one such as pure phosphoric acid, in whatever concentration, or in cold solutions. Similarly, it can also resist up to 10% diluted hot phosphoric acid solutions. Stainless steel 304 performs well in freshwater service with low levels of chlorides (less than 100ppm). At a higher chloride level containing environment, the material is susceptible to crevice corrosion and pitting. Stainless steel grade 304L is not recommended for service in marine environments by 304l stainless steel flanges manufacturers. It is considered to be one of the most economical, yet versatile alloys amongst 304l stainless steel flanges suppliers. Sa 182 gr f304l is a corrosion-resistant alloy suitable for a broad range of general-purpose applications. Click on the given link for more details on the 304l ss flanges price. Also We offer wide range of Stainless Steel ASTM A182 304L Flanges such as SS 304L Slip On Flanges, SS 304L Weld Neck Flanges, SS 304L Socket Weld Flanges, SS 304L Blind Flanges, SS 304L Orifice Flanges, SS 304L Spectacle Blind Flanges, SS 304L Screwed/Threaded Flanges, SS 304L Reducing Flanges, SS 304L Ring Type Joint Flanges (RTJ) etc.


Standard Specification For Stainless Steel ASTM A182 304L Industrial Flanges


Specifications : ASTM A182 / A240 & ASME SA182 / SA240

Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.

Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

Size : 1/2" (15 NB) to 48" (1200NB)

Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Flange Face Type : Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)



Call@ 9987994248. Find here online the most recognized Manufacturers, exporter & Supplier of Stainless Steel 304L Flanges, SS 304L Pipe Flanges, UNS S30403 Flanges, Buy 304L Stainless Steel Plate Flanges at the best Price in Mumbai, Pune, Ahmedabad, Chennai, Thane, Indore, Oman, France, Canada, Brazil, Singapore, Peru, UAE, Qatar, India.

Other Names: ASTM A182 304L Stainless Steel, stainless steel 304L, SS UNS S304L00, SS 304L Flange

Material: Stainless Steel Grade 304L

Brand: Fitwel Industries LLP

Manufacturer: Fitwel Industries LLP

Suppliers & Exporter: Fitwel Industries LLP

Rating: 4.3/5 based on 83 customer reviews


ASTM A182 F304L Stainless Steel Pipe Flanges

Forged and Plate Flanges

Products Size
ASTM A182 SS 304L Slip-On Flanges ASTM A182 SS 304L Threaded Flanges Sizes 1/8″ – 36″
Raised Face or Flat Face
ASTM A182 SS 304L Weld Neck Flanges ASTM A182 SS 304L Socket Weld Flanges
ASTM A182 SS 304L Blind Flanges ASTM A182 SS 304L Reducing Flanges
ASTM A182 SS 304L Lap Joint Flanges ASTM A182 SS 304L Plate Flanges
ASTM A182 SS 304L Orifice Flanges ASTM A182 SS 304L Forged Flanges
ASTM A182 SS 304L Ring Type Joint Flanges ASTM A182 SS 304L Square Flanges

SS 304L Flange Standards / Types And Pressure Class :

ASME/ANSI B 16.5 Welding Neck Flange, Slip on Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Ring Type Joint Flange
PRESSURE CLASS 150, 300, 400, 600, 900, 1500, 2500
ASME/ANSI B 16.47 Welding Neck Flange, Blind Flange [Series A & B]
PRESSURE CLASS 75, 150, 300, 400, 600, 900
ASME/ANSI B 16.36 Welding Neck Flange, Slip on Flange, Threaded Flange
PRESSURE CLASS 300, 400, 600, 900, 1500, 2500
BS 4504 SEC 3.1 Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange
PRESSURE CLASS PN 2.5 TO PN 40
BS 4504[PART 1] Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange
PRESSURE CLASS PN 2.5 TO PN 400
BS 1560 BOSS Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, Lapped Flange
PRESSURE CLASS 150, 300, 400, 600, 900, 1500, 2500
BS10 Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange
TABLE D, E, F, H
DIN FLANGES DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673
PRESSURE CLASS PN 6 TO PN 100

ASME SA182 304L Stainless Steel Flanges Equivalent Grades
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 304L 1.4306 / 1.4307 S30403 SUS 304L 3304S11 03Х18Н11 Z3CN18‐10 X2CrNi18-9 / X2CrNi19-11

Types Of Grade Stainless Steel Flanges

Chemical Composition of Grade F304L Stainless Steel Pipe Flanges
Grade C Mn Si P S Cr Mo Ni N
SS 304L 0.035 max 2.0 max 1.0 max 0.045 max 0.03 max 18 – 20 - 8 – 13 -

Mechanical Properties of ASTM A182 SS 304L Plate Flanges
Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

ASTM A182 F304L Stainless Steel Flanges Available Types
Stainless Steel 304L Flanges Stainless Steel 304L EN 1092-1 Flanges
Stainless Steel 304L BS 4504 Flanges Stainless Steel 304L Forged Flanges
Stainless Steel UNS S30403 Flanges Stainless Steel 304L Slip on Flanges
SS 304L Flat Flange Suppliers ANSI 304L Stainless Steel Blind Flange
SS 304L Weld Neck Flanges Dealer SS 304L Socket weld Flanges Exporter
SS 304L Long Weld Neck Flanges Stockholder Steel 304L Threaded Flanges Distributors
Stainless Steel SUS 304L Reducing Flanges SS 304L Ring Type Joint Flanges Manufacturer
Stainless Steel DIN 1.4307 Orifice Flange Stainless Steel BS 3304S11 Spectacle Blind Flanges
Stainless Steel 304L WNRF Flange Stainless 304L SORF Flanges
ANSI B16.5 SS 304L RTJ Flanges SS 304L Screwed Flanges Stockist
ASTM A182 SS 304L Lap Joint Flanges ASME SA182 SS 304L BLRF Flange
Stainless Steel 304L Raised Face Flanges 304L SS Nipoflange
A182 SS 304L Square Flanges ASME SA182M SS 304L SWRF Flange
Steel 304L Tongue & Groove Flanges SS 304L Male & Female Flanges
Stainless Steel 304L DIN Flanges SS 304L ASME B16.5 Flanges

Stainless Steel 304L AISI, ASME, DIN, BS, EN Flanges Application

ASTM A182 304L Pipe Flanges are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A182 304L Stainless Steel Flanges through a worldwide network of stock-keeping branches. These ASTM A182 304L Flange is use in various industries like :

  • Stainless Steel 304L Flanges uses in Oil and Gas Pipeline
  • ASTM A182 SS 304L Pipe Flanges uses in Chemical Industry
  • Grade 304L Stainless Steel Flanges uses in Plumbing
  • Stainless Steel ASTM A182 304L Flange uses in Heating
  • ASTM A182 304L Plate Flanges uses in Water Supply Systems
  • ASTM A182 304L Stainless Steel Forged Flanges uses in Power Plant
  • SS 304L Flanges uses in Paper & Pulp Industry
  • 304L SS Flanges uses in General Purpose Applications
  • ASME SA182 Stainless Steel 304L Industrial Flanges uses in Fabrication Industry
  • Stainless Steel 304L Flanges uses in Food Processing Industry
  • ANSI SS 304L Flanges uses in Structural Pipe
